Ref. 7722L VHF-UHF indoor amplifier 4G

Go to products

7722L VHF-UHF indoor amplifier 4G

1 input (40-320+ 470-790 MHz) / 2 outputs / gain VHF: 15-30 dB / gain UHF: 18-28 dB


  • 1 input: 40-320 MHz + 470-790 MHz
  • 2 outputs
  • Adjustable VHF gain: 15-30 dB
  • Adjustable UHF gain: 18-28 dB
  • Switchable remote power
  • Power LED indicator

Back: Ref. 7720L2 Next: Ref. 7722L2

Specifications

7722L
Frequency range MHz 40-320 + 470-790
Adjustable gain dB VHF: 15-30
UHF: 18-28
Noise figure dB 3.0 typ.
Max. output level  dBµV 107
Return loss (input/output)  dB 10
Isolation between outputs  dB 15
Remote power  - 24V / 55mA
Power - 230V~/6.9VA
Mounting - Wall or DIN rail mounting
Dimensions mm 137 x 92 x 42
