Ref. 9939 1 way tap -10 dB / 4x SAT + 1x TERR.

Go to products

9939 1 way tap -10 dB / 4x SAT + 1x TERR.

5 lines 1 way tap -10 dB / 4x SAT + 1x TERR.


  • 2-way satellite tap
  • Terrestrial input / output
  • DC power pass
  • Loss: 10dB (tap loss) / 1dB ( through loss)

Back: Ref. 9937 Next: Ref. 9942

Specifications

9939
Inputs - 4 SAT + 1 TERR
Outputs - 5 taps / 5 through
Frequency range  MHz SAT.: 950-2300
TERR.: 5-862
Tap Loss dB SAT.: -10
TERR.: -13
Through Loss dB SAT.: -1
TERR.: -1
DC power pass in / tap / out - Yes
Dimensions  mm 142 x 158 x 51
EAN - 5404041102542
